Product Specifications

• Product name Xiaomi Smart Doorbell 3S
• Model MJML07-FJ
• Product dimensions 146 x 52 x 29 mm
• IP rating IP65
• Battery capacity 5200mAh (typ)
• Rated input 5V⎓2A (Type-C port)
• 8-24VAC, 10-40VA, 50-60Hz (bell AC adapter)
• Wireless connectivity Wi-Fi IEEE 802.11b/g/n 2.4GHz
• RF 433MHz
• Infrared light 940nm
• Save Save in the cloud
• Charging temperature 0℃ to 45℃
• Operating temperature -20℃ to 50℃
• Operating humidity 10%-90% RH, no condensation

Specifications of the Bellows

• Model MJJSQ04-FJ
• Product dimensions 60 × 60 × 39.6 mm
• Rated input 5V⎓1A
• Wireless connectivity RF 433MHz (receive only)
• Operating temperature 0℃ to 45℃
• Operating humidity 10%-90% RH, no condensation

Contents of packaging

• Smart doorbell x1
• Mounting base × 1
• Angle slot × 1
• Bell × 1
• Removal pin × 1
• Type-C charging cable × 1
• Set of screws (wall screw × 2, wall plug × 2, corner base screw × 2)
• U-type extension cable × 2
• Insulating cap × 2
• U-type double terminal wire × 1
• User manual × 1
• Warning sticker × 1
• Guarantee × 1
• User manual x1
• Guarantee x1
